| Main
function |
|
|
 |
|
16
VIDEO / 16 AUDIO INPUT |
| |
Recording
16 video and 16 audio simultaneously. The video and audio
will be playback synchronously when you playback a video
file. |
| |
|
|
 |
|
RECORDING
SPEED |
| |
16
videos up to 480/400 fps (NTSC/PAL) real time recording
base on full D1(720x480/720x576) resolution |
| |
|
|
 |
|
REAL
TIME MONITORING |
| |
480/400
(NTSC/PAL) real time Display. |
| |
|
|
 |
|
HIGH
RESOLUTION |
| |
720x480/720x576
High resolution image quality |
| |
|
|
 |
|
INTERLACE
& NON-INTERLACE |
| |
Support
Interlace and non-interlace video signal. Jetting free
video with fast-moving motion under 720x480/720x576 resolutions
display. |
| |
|
|
 |
|
OPERATION
TOOLS |
| |
Support
Front keyboard, Remote Controller and Mouse for operation. |
| |
|
|
 |
|
NETWORK
VIDEO TRANSMISSION |
| |
Support
video transmission via ADSL, Cable Modem, ISDN, PSTN |
| |
|
|
 |
|
EASY
PICTURE RETRIEVAL
Instant picture retrieval by date/time and camera number |
| |
|
|
 |
|
VARIOUS
FUNCTIONS
Various functions (multi playback, motion detection, schedule,
backup, etc.) |
| |
|
|
 |
|
COMPAC
VIDEO STORAGE
Using MPEG 4 VBR (Variable Bit Rate) Algorithm. Videos
are compressed down to an average of file size between
1.5~8.5Kb/Frame @ 720x480 resolution. |
| |
|
|
 |
|
AVI
FILE
Support standard Codec and video of Windows, the video
file can playback either the current Media Player of Microsoft. |
| |
|
|
 |
|
EASY
OPERATION
Graphical User Interface, easy to operation. |
| |
|
|
 |
|
STABILITY
Embedded O.S. and Watchdog recovers system after power
failure. |
| |
|
|
 |
|
DUAL
MONITOR DISPLAY
Dual view allows live and eMap or playback screens to
be viewed in separate monitors |
| |
|
|
 |
|
STORAGE
Build in six HDD capabilities, up 2 T Byte storage space. |
| |
|
|
 |
|
BACK
UP
E-Z Backup Program onto External Storage Device (HDD,
CD-RW, DVD-RW, etc.) & play them with Windows Media
Player or our “EZ Playback” Software. |
| |
|
|
 |
|
LAN
PLAYBACK
The EzLANPlayback software allows playback the video clips
of DigiCap II DVR via LAN. This function will let the
HDD of DigiCap II DVR it just like the parts HDD of EzLANPlayback’s
PC. |
| |
|
|
 |
|
E-MAP
An e-map is a graphical overview of a site, indicating
the locations of the cameras and sensors. |
| |
|
|
 |
|
MOTION
DETECTION
Built-In Software Motion Detection (or Optional Hardware
Motion Sensor) with selectable zones & sensitivity
control. |
| |
|
|
 |
|
EVENT
LOG
Will show records for user logins, video loss and motion
detection. |
| |
|
|
 |
|
PASSWORD
Multiple levels, from administrator to user. |
| |
|
|
 |
|
TRIPLEX
OPERATION
Simultaneous Live Display, Playback and Remote-View. |
| |
|
|
 |
|
REMOTE
SETTING
Thru our software, user can remotely access to DVR and
change local settings / configurations when necessary. |
| |
|
|
 |
|
WEB
BROWSER
From anywhere, connect to your DVR server and search &
playback the video clips of the server remotely, by options
of archiving or downloading. |
| |
|
|
 |
|
P/T/Z
& I/O
Control your PTZ or Speed Dome cameras and I/O ports with
a click of mouse, locally and remotely from anywhere.
(Optional) |
| |
|
|
 |
|
REMOTE
ACCESS
Connect to multiple sites simultaneously and record /download
/playback video clips at any remote location. View/Playback
up to 36 cameras per page from anywhere at any time. |
| |
|
|
 |
|
IR
Remote Controller
Optional IR remote controller can control up to 16 units
of DVR |
